MECHANICAL CHARACTERISTIC

IP degree of protection : External enclosure: IP4X | Internal separation : IP2X
Surface Protection : Anti Rust Treatment | Epoxy Power Coating | Oven Baked
Standard Colours : RAL 7032 or Similar | Other Colors Upon Request
Access : Front
Cable Entry : Bottom
Ventilation : Mechanical Air Louvers

MATERIAL

ONE DOOR – 1.5MM THICKNESS

Dimension : Length x Height x Depth (inch)	Dimension: Length x Height x Depth (MM)
8” x 10” x 5”	200MM X 250MM X125MM
10” X 12” X 5”	250MM X 300MM X 125MM
12” X 14” X 6”	300MM X 350MM X 150MM
14” X 16” X 6”	350MM X 400MM X 150MM
16” X 18” X 6”	400MM X 450MM X 150MM
18” X 20” X 7”	450MM X 500MM X 175MM
20” X 22” X 7”	500MM X 550MM X 175MM
22” X 24” X 7”	550MM X 600MM X 175MM
23” X 26” X 7”	575MM X 650MM X 175MM
24” X 28” X 7”	600MM X 700MM X 175MM
26” X 30” X 8	650MM X 750MM X 200MM
28” X 28” X 8”	700MM X 700MM X 200MM

TWO DOOR – 1.5MM THICKNESS

Dimension : Length x Height x Depth (inch)	Dimension: Length x Height x Depth (MM)
28” X 32” X 8”	700MM X 800MM X 200MM
30” X 34” X 8”	750MM X 850MM X 200MM
32” X 36”X 8”	800MM X 900MM X 200MM
34” X 38” X 8”	850MM X 950MM X 200MM
36” X 38” X 8”	900MM X 950MM X 200MM
36” X 40” X 8”	900MM X 1000MM X 200MM
36” X 42” X 8”	900MM X 1050MM X 200MM
38” X 42” X 8”	950MM X 1050MM X 200MM
32” X 46” X 8”	800MM X 1150MM X 200MM
36” X 46” X 8”	900MM X 1150MM X 200MM
42” X 46” X 8”	1050MM X 1150MM X 200MM
44” X 46” X 8”	1100MM X 1150MM X 200MM

TWO DOOR – 1.5MM @ 1.8MM THICKNESS

Dimension : Length x Height x Depth (inch)	Dimension: Length x Height x Depth (MM)
46” X 50” X 9”	1150MM  X 1250MM X 225MM
46” X 52” X 9”	1150MM X 1300MM X 225MM
46” X 54” X 9”	1150MM X 1350MM X 225MM
46” X 56” X 9”	1150MM X 1400MM X 225MM
42” X 54” X 10”	1050MM X 1350MM X 250MM
46” X 54” X 10”	1150MM X 1350MM X 250MM
42” X 60” X 10”	1050MM X 1500MM X 250MM
46” X 60” X 10”	1150MM X 1500MM X 250MM
